ALEX
-
About ALEX
About ALEX
ALEX aluminum extensions are designed to support scalable, repeatable field installation across utility-scale solar builds. Pre-engineered to project specifications, they help standardize wiring runs, streamline deployment, and sustain dependable performance over the service life of the system.
-
01Factory-welded CU-AL transition joints with overmolded IP68 protection to prevent galvanic corrosion.
-
02Optimized for seamless integration between modules, combiners, inverters, and Voltage LYNX® systems.
-
CU-ALCost-effective hybrid extension
-
2kVCertified by UL
-
![c1icon01[1] 2.svg](/Public/Uploads/uploadfile/images/20260128/c1icon01[1]2.svg)
100%Pre-assembled and tested
-
![692fff6b3c7fe11[1].svg](/Public/Uploads/uploadfile/images/20251218/692fff6b3c7fe11[1]-173.svg)
5 YearsProduct warranty
Specifications & Key Benefits
-
Significant CapEx savings
-
Factory pre-assembled and 100% tested
-
Maintains electrical performance at longer distances
-
Custom-engineered to fit exact row dimensions
-
Friction-welded copper-aluminum joints ensure safety and conductivity
-
IP68 overmold for environmental protection
-
Delivered ready to install on reels
-
5-year standard warranty (extendable)
-
US
-
Voltage Rating2000V DC
-
2kV AL Conductor Isc.6-1 AWG (70-86A)
-
2kV CU Conductor Isc.12-6 AWG (35-86A)
-
Operating Temp.-40°C ~ 90°C
-
-
EU
-
Voltage Rating1500V DC
-
1.5kV AL Conductor Isc.16-35mm² (70A-130A)
-
1.5kV CU Conductor Isc.6-16mm² (70A-130A)
-
Operating Temp.-40°C ~ 85°C
-
