About IBEX

IBEX is a factory-assembled string harness for cost-effective, lightweight wiring in utility-scale PV systems, using a copper-aluminum hybrid design to balance efficiency and ampacity.

IBEX PLUS extends this platform with a high-aluminum architecture for further weight and cost optimization, enabling plug-and-play installation and reliable performance at scale.

97%

Aluminum Adoption
Flexible AL

Main Power Conductor
2kV

Certified by UL
5 Years

Product Warranty

Where IBEX Works Best

Utility-scale PV arrays with dense stringing and extended layouts

Utility-scale PV arrays with dense stringing and extended layouts

Tracker arrays with variable row lengths or terrain constraints

Tracker arrays with variable row lengths or terrain constraints
Projects with high-cost sensitivity

Projects with high-cost sensitivity

Sites prioritizing speed, standardization, and code compliance

Sites prioritizing speed, standardization, and code compliance

Key Features

IBEX PLUS
IBEX

97% aluminum design for ultra-lightweight and cost-efficient harness solutions
Flexible aluminum main conductors rated up to 143A with 1 AWG
Each drop configurable for copper or flexible aluminum conductors
Seamlessly compatible with LYNX and Combiner Box for maximum site layout flexibility
UL 9703 and CSA certified
IP68 environmental protection

Technical Data

US
- Voltage Rating

  2000V DC
- 2kV AL Conductor Isc.

  6-1 AWG
  (70-143A)
- 2kV CU Conductor Isc.

  12-6 AWG
  (35-86A)
- Operating Temp.

  -40°C ~ 90°C

Download Spec Sheet (US)

Hybrid Cu-Al construction balances performance and material cost
Supports up to 143A with 1 AWG aluminum and 86A with 6 AWG copper conductors
Seamlessly integrates with LYNX Trunk Bus architecture
100% factory-assembled and site-customized for each project
UL 9703 and CSA certified
IP68 environmental protection
